What a flywheel does (theory, in plain terms)
- The flywheel is a heavy, machined disc bolted to the rear of the crankshaft. It has three main jobs:
1. Store and smooth rotational energy so the crank’s firing pulses don’t make driveline speed jump — think of it as a bicycle’s heavy rim that keeps you coasting smoothly between pedal strokes.
2. Provide a friction surface and alignment location for the clutch (on manual transmissions) so engine power can be transferred or disconnected.
3. Provide the ring gear teeth the starter motor engages to crank the engine.
- If the flywheel surface is burnt, warped, cracked, or the ring gear teeth are damaged, the clutch will chatter or slip, you’ll get vibration, starter engagement problems, or accelerated wear elsewhere.

Main components you’ll encounter and what each does
- Flywheel (disc): heavy, machined mating face to clutch, bolted to crank. Has friction surface (or flat surface if clutch friction disc presses to it).
- Ring gear: pressed/bolted to the flywheel outer diameter; teeth for the starter pinion.
- Flywheel bolts/studs and washers: secure flywheel to crank flange. Often torque-to-yield or single-use — must follow spec, often replaced.
- Dowel pins / location pins: keep flywheel indexed on crank flange so it sits concentric.
- Pilot bearing / bushing (in crank nose or flywheel center): supports transmission input shaft tip; reduces wobble.
- Clutch disc (friction disc): splines to input shaft, pressed between flywheel and pressure plate.
- Pressure plate: bolts to flywheel and clamps clutch disc; contains springs/diaphragm.
- Release bearing / throwout bearing and release mechanism: moves the pressure plate fingers to disengage clutch.
- Rear main seal: seals crankshaft at the rear; often accessible when flywheel removed and commonly replaced then.
- Bellhousing / transmission input shaft: will separate from engine to access flywheel.
- Starter motor / Bendix: meshes with ring gear to crank engine.
- Flywheel holding tool / flywheel locking tool: prevents flywheel from turning while loosening/tightening bolts.
- Clutch alignment tool: centers the clutch disc on the crank pilot so the transmission input shaft will slide in.

Why and when you need to service/replace the flywheel
- Symptoms that indicate flywheel work is needed:
- Slipping clutch under load (engine revs rise with no proportional movement).
- Clutch chatter or judder on engagement.
- Excessive driveline vibration from idle to low rpm.
- Starter grinding or failure to engage.
- Visible cracks, heat spots (blue/black patches), scoring, or lip build-up at the friction face.
- Oil contamination on the friction face (rear main or transmission seal leak).
- Typical causes:
- Overheating from repeated slipping causes glazing/hard spots and changes flatness.
- Mechanical shock or torque spikes causing cracks or broken bolts.
- Poor installation (incorrect torque, missing dowel, wrong alignment) causing runout or bolt shear.
- Normal wear over high mileage.

Before you start: safety and general prep
- Work on a flat surface, wheels chocked, parking brake on.
- Disconnect negative battery terminal (to prevent starter engagement or shorting).
- Support vehicle with jack stands rated for the vehicle — medium-duty truck requires appropriate heavy support and often a lift.
- Use a transmission jack and an engine support or hoist as required — the transmission is heavy.
- Work with clean, well-lit area and have a parts tray for bolts.
- Use proper personal protective equipment: gloves, eye protection, safety boots.

Tools and consumables
- Basic hand tools: sockets, ratchet, extensions, breaker bar, wrenches.
- Torque wrench (calibrated) and, if required by spec, torque-angle gauge.
- Flywheel holding tool or suitable pin wrench to prevent rotation.
- Transmission jack, engine support/hoist.
- Clutch alignment tool matching spline size.
- Pilot bearing puller / drift.
- Dial indicator for runout, straightedge, feeler gauges.
- Flywheel dressing/resurfacing equipment (or send to machine shop).
- Thread locker (per manual), anti-seize (only if manual calls for it), replacement bolts (factory).
- Brake cleaner, lint-free rags, solvent for cleaning.
- Replacement rear main seal / pilot bearing / clutch kit as needed.
- Dye-penetrant kit for crack inspection (optional but recommended on heavy trucks).

High-level step-by-step procedure (manual-transmission style)
Note: follow the Hino GH1H workshop manual for model-specific steps, torque values, bolt sequences, and safety details. Below is the standard flow and where to be careful.

1) Prepare vehicle
- Disconnect battery negative.
- Drain transmission fluid if needed (for safety & lighter).
- Raise and safely support truck; remove driveline (prop shaft) if required.
- Remove any engine/transmission-related components blocking bellhousing removal: air lines, wiring harnesses, starter motor (mark position), clutch slave or hydraulic lines, crossmembers, mounts as per manual.

2) Separate transmission from engine
- Support transmission with a transmission jack.
- Remove transmission-to-engine bellhousing bolts in appropriate sequence; use caution because the weight tends to shift.
- Carefully slide transmission back far enough to expose clutch and flywheel (but don’t drop it). You can leave it supported on the jack and lower a bit.
- Remove clutch cover (pressure plate) bolts in star pattern while supporting pressure plate; remove friction disc and inspect.

3) Remove flywheel
- Clean area around flywheel to avoid dirt contamination.
- Mark the flywheel orientation to the crank (a reference mark) only if reusing flywheel and manual allows; many manufacturers require replacing bolts and may recommend new flywheel so marking isn’t always used.
- Use a flywheel holding tool to prevent rotation; loosen bolts in a criss-cross pattern to avoid distorting the flywheel. If bolts are seized, apply heat carefully to bolt head or use descending-impact methods, but avoid damaging crank threads.
- Remove flywheel bolts, washers; ease flywheel off the crank. Be ready; it’s heavy. Use hoist/engine support and assistance.

4) Inspect flywheel and surrounding parts
- Visual: check friction face for glazing, heat-stressed discoloration (blue/purple), cracks, deep grooves, lip, and ring gear tooth condition.
- Check ring gear seating and teeth for impact or missing teeth.
- Measure flywheel surface runout with dial indicator against a reference; check with a straightedge for warping.
- Check for cracks with dye-penetrant, especially near bolt holes and around the circumference.
- Inspect bolt holes for elongation or distortion.
- Inspect pilot bearing/bushing for play or roughness; replace if any roughness or play.
- Inspect crank flange face for burrs, corrosion, or damage; clean but do not remove material.
- Check rear main seal for leakage; replace while transmission is out if any sign of oil.

Accept/refurbish/replace decisions
- Resurface flywheel if minor glazing, slight scoring, or unevenness — machine shop must do this to manufacturer thickness and runout tolerances. Do not remove more material than allowed — thinner flywheel changes clutch geometry and balance.
- Replace flywheel if cracks, excessive thickness removal required, excessive runout, missing ring gear teeth, or bolt hole damage.
- Always replace flywheel bolts if they are torque-to-yield or specified as single-use. If manual allows reuse, check threads and torque spec. Use threadlocker if specified.

Reinstallation (order and key points)
- If replacing pilot bearing: press new pilot bearing into crank or flywheel hub as directed, ensuring correct orientation and full seating (do not hammer on internal races).
- If resurfaced or new flywheel: clean mating surfaces with solvent to remove oil/grease.
- Use new bolts if required; lightly lubricate threads or apply specified threadlocker. Follow the manual for whether threads get oil, anti-seize, or must be dry.
- Hand-locate flywheel on dowels. Start bolts by hand to avoid cross-threading.
- Tighten bolts in specified criss-cross sequence in stages to recommended torque. If torque-angle is required, follow that exact procedure.
- Important: incorrect torquing can shear bolts or cause flywheel misalignment and catastrophic failure.
- If the ring gear is separate and required to be pressed on or replaced, ensure it’s correctly seated and heat-fit procedure followed by shop practice or manufacturer instructions.
- Install pressure plate and clutch disc using alignment tool; torque pressure plate bolts in star pattern to spec.
- Replace or service release bearing and ensure release mechanism properly lubricated per manual (do not get grease on friction surfaces).
- Replace rear main seal if removed.
- Reinstall transmission: align input shaft with clutch spline and pilot bearing; use a transmission jack and guide studs (or dowels) to align and support.
- Torque bellhousing bolts and transmission mount bolts to spec.
- Reinstall starter, driveline, and any removed components. Reconnect battery.

Final checks and test
- Refill transmission/driveline fluids to correct level.
- Check for leaks around rear main and bellhousing.
- With vehicle safely on stands or after lowering, start engine and test clutch engagement/disengagement with handbrake applied.
- Test drive at low speed to confirm no chatter, slipping, vibration, or starter engagement issues.
- Re-check torque on critical fasteners after initial run period if manual requires it.

What can go wrong (and how to avoid)
- Flywheel bolts loosen or shear: caused by under/over torque, reused torque-to-yield bolts, or oil on threads. Prevent by using correct bolts, correct torque procedure, clean threads, and threadlocker if specified.
- Imbalance or vibration: caused by incorrect flywheel orientation, missing dowels, uneven resurfacing, or foreign material. Prevent by correct indexing, balanced assembly, and professional resurfacing.
- Clutch slipping after reassembly: caused by glazed surfaces, contaminated friction material (oil/grease), incorrect torque on pressure plate, or wrong disc orientation. Prevent by cleaning, avoiding contamination, correct torque, and correct clutch kit.
- Starter pinion damage or grinding: caused by damaged ring gear, incorrect starter positioning, or misalignment after assembly. Inspect ring gear and starter mount, fix alignment.
- Pilot bearing failure causing input-shaft wobble: replace pilot bearing if noisy or loose; improper installation will cause early failure.
- Rear main seal leak after reassembly: caused by damaged crank surface, improper seal installation, or debris. Clean and replace seal properly with correct installer tool.

Measurement and tolerance checks (general guidance)
- Use the factory workshop manual for exact tolerances (runout, thickness, bolt torque, torque-angle).
- Typical checks you should perform:
- Flywheel surface runout with dial indicator — small microns of runout cause clutch chatter. If runout exceeds spec, resurface or replace.
- Visual crack check with dye penetrant on the ring and around bolt holes.
- Check pilot bearing radial/axial play and replace if rough or loose.
- Ensure pressure plate spring height/free play and pressure plate torque per spec.
- If you can’t access factory values, do not guess torque or allowed thickness removal: incorrect values risk catastrophic failure.

Analogies and simple pictures in your head
- Flywheel = heavy bicycle rim that smooths pedaling pulses and stores momentum.
- Clutch = a hand brake that pinches the rim (flywheel) to transmit motion — if rim is warped or oily, the brake slips.
- Pilot bearing = the small bearing that centers the bicycle wheel axle in the frame — if it’s rough, the axle wobbles and gears don’t mesh smoothly.
- Flywheel bolts = the wheel hub nuts; if they’re loose or stripped, the wheel shifts and can come off.

Practical tips for beginners
- Take lots of photos as you disassemble to remember wiring and bracket positions.
- Keep fasteners labeled and in order.
- Replace wear items while you have access (pilot bearing, rear main seal, release bearing).
- If you need a surface finish, let a reputable machine shop resurface and balance the flywheel if required.
- Never sand or file the friction face with power tools yourself — use proper resurfacing equipment.
- When in doubt about torque or process, get the official Hino workshop manual or consult a Hino dealer technician — torque and angle specs are critical.

Final note (must-follow)
- This is a detailed practical guide, but Hino GH1H-specific torque values, bolt sequences, and tolerances must come from the official Hino Super F Series GH1H Workshop/Service Manual. Use those exact numbers and procedures for safety and longevity.
