1) Theory — what the timing belt system does and why it fails
- Function: the timing belt mechanically links the crankshaft to one or more camshafts (and sometimes balance shafts/water pump) so valve opening/closing is synchronized with piston position. Proper timing controls intake/exhaust valve events and combustion phasing.
- Components: belt (toothed), cam sprockets, crank sprocket, tensioner (spring or hydraulic), idler pulleys, timing covers, often water pump driven by the belt on many Kia V6s.
- Failure modes: belt wear/age (tooth wear, cracking, glazing), stretched belt, seized/failed tensioner or idler, or a leaking water pump contaminating/accelerating belt failure. On an interference engine (common in Carnivals/Sedonas) belt failure = pistons strike open valves → bent valves, possible piston/head damage.
- How the repair fixes it: replacing the belt and worn components restores correct mechanical phase relationship between crank and camshaft(s), corrects belt tension and pulley alignment, removes contaminated/worn parts, and prevents slip or breakage that would desynchronize the engine and cause valve/piston collision or poor running.

2) Ordered repair procedure (generalized for Kia Carnival / Sedona engine families — consult factory manual for model-specific marks, torque values, and special tools)
Safety: work on a cold engine, disconnect negative battery, support vehicle securely if raising it, wear eye protection.

Preparation
1. Gather parts/tools: new timing belt, tensioner, idlers, water pump (recommended), crank/cam seals if leaking, proper belt routing diagram, torque wrench, crank holding tool or impact, cam lock tools if required, breaker bar, sockets, screwdrivers, jack stands.
2. Drain coolant if removing water pump.

Removal — gain access and expose timing belt
3. Remove engine covers, intake resonator, accessory drive belts, crankshaft pulley/serpentine pulley (may require holding tool and possibly breaking crank bolt torque).
4. Remove lower/upper timing covers to expose belt and sprockets.
5. Rotate engine by hand (via crank bolt) to bring engine to Top Dead Center (TDC) for cylinder 1 on compression stroke. Align factory timing marks on crank and cam sprockets. Confirm alignment in manual-specified way (mark positions with paint if needed). This verifies baseline and avoids misalignment.

Locking / safety
6. Lock camshafts/crank as required with cam locks or by double-checking marks; do not let cam/crank move once locked.

Removal of old parts
7. Loosen and remove the belt tensioner so the belt can be removed. Remove belt carefully; if camshafts move, realign before continuing.
8. Remove idlers and inspect bearings for play/noise.
9. Remove and inspect water pump; replace it if old or leaking (recommended when doing belt job).
10. Inspect cam/crank seals and replace if leaking.

Installation — fit new parts and set timing
11. Install new idlers, tensioner, and water pump; torque to factory specs.
12. Route the new timing belt around crank sprocket, cam sprocket(s), idlers, and tensioner following the correct routing and orientation. Ensure belt teeth fully seat on sprocket teeth.
13. Apply initial tension per procedure for your tensioner type (pre-load spring, jump-pin, or hydraulic procedure). For spring tensioners, compress/load and lock per manual; for auto tensioners, set per specified method.
14. Re-check timing marks: with belt installed and tension applied, ensure crank and cam marks are still exactly aligned. If not, remove belt and re-seat — do not force alignment.

Final tensioning and verification
15. Rotate the engine by hand (2 full revolutions of the crankshaft) clockwise using the crank bolt. Stop at TDC and recheck timing marks. This verifies there is no interference or skipped teeth.
16. Check belt tension at spec point(s). Adjust tensioner if necessary. Re-check cam timing alignment after tensioning.
17. Reinstall timing covers, crank pulley (torque to spec), accessory belts, refill coolant, reconnect battery.

Start-up and test
18. Start engine and listen for abnormal noises (squeal, rattle). Let reach operating temp, check for coolant leaks and proper idle.
19. Road test under varied load; recheck timing cover area and pulleys for leaks/noise after a short test drive.
20. Re-torque critical fasteners after warm-up if specified by manual.

Why each major action fixes the fault (concise)
- Replacing the belt: removes worn/stretching belt that can skip teeth or break — restores tooth engagement and accurate cam/crank phase.
- New tensioner/idlers: corrects loss of proper belt tension or pulley misalignment that causes belt flap, noise, uneven wear, or tooth skipping.
- Replacing water pump: eliminates a common source of belt contamination/leakage and prevents early belt failure; a seized pump would lock up the belt.
- Correct alignment and rotation verification: ensures cams and crank are synchronized; rotating two turns proves there's no interference and that the installation didn’t skip teeth.
- Replacing seals and torquing fasteners: prevents external contamination and ensures components remain fixed under load.

Key checks and common pitfalls (short)
- Always confirm TDC on compression stroke for cylinder 1, not just cam mark alignment alone.
- Never force the belt or force sprockets; misalignment causes skipped teeth.
- Use manufacturer timing marks and torque specs — incorrect torque on tensioner or crank pulley can lead to failure.
- If the engine is interference-type, take extra care: a single skipped tooth can cause catastrophic valve damage.
- Replace water pump, tensioner, and idlers as a set when doing the belt to avoid early rework.

End.
