Quick summary (what you’ll get): a plain-English explanation of how Toyota 5S‑FE power steering works, why it fails, what each component does, and step‑by‑step repair procedures for the common jobs a beginner will do (pump, hoses, rack/tie‑rod/boots), plus safety, tools, and bleeding. No fluff.

Safety first
- Work on a flat surface, chock rear wheels, use jack stands (never rely on a jack alone).
- Wear goggles and gloves. Power steering fluid is slippery; clean spills immediately.
- Don’t run the pump dry — it will fail quickly.
- Keep parts and fasteners organized and torqued to spec from the factory manual. I will say “use factory torque specs” where exact numbers matter.

Theory — how the system works (analogy included)
- The system is a simple hydraulic assist for your hands. Think of it like a bicycle pump (pump = heart) pushing fluid through hoses into a cylinder that helps move the steering rack (the piston).
- Engine-driven pump draws low‑pressure fluid from a reservoir, pressurizes it and sends it through a high‑pressure hose to the steering rack (rack‑and‑pinion). The rack carries a piston or valve assembly that uses that pressure to help move the rack left or right when you turn the wheel. Excess fluid returns via a low‑pressure return hose back to the reservoir.
- A pressure relief valve prevents dangerous overpressure; check valves/directional valves route pressure to the side of the rack that needs assist.
- The steering column connects to a pinion gear that moves the rack; tie rods connect the rack to the steering knuckles. Boots protect the rack seals from dirt.

Main components (detailed)
- Power steering pump: belt-driven unit mounted on engine. Inside: rotor/vanes and a housing. Creates flow and pressure. Has a pulley, mounting flange, inlet and outlet fittings, sometimes a reservoir integrated (often on older Toyotas it’s separate).
- Reservoir: small tank that holds fluid, has a pickup tube and a cap with a dipstick or level mark. Often uses ATF (Dexron) or Toyota PS fluid — check label or manual.
- High‑pressure hose: steel‑braided or reinforced hose carrying pressurized fluid from pump outlet to steering gear. Uses flare fittings or banjo fittings with crush washers.
- Return/low‑pressure hose: carries fluid back from rack to reservoir; usually rubber and clamps.
- Steering rack (rack‑and‑pinion with power assist): the rack housing contains the rack, pinion valve and piston. Seals and boots prevent fluid leak and keep dirt out. Mounts to body or subframe.
- Tie rods (inner + outer): connect rack to steering knuckle. Inner often threads into rack; outer threads onto inner and connects to knuckle via ball joint.
- Boots (rack gaiters): protect inner tie rod and rack seals from dirt/water.
- Belt and tensioner: drives the pump. Belt slip reduces pump output.
- Fittings and O‑rings/crush washers: seal pressure fittings.
- Steering shaft coupler/pinion shaft: U‑joints and pinch bolts link the steering column to the rack; must be aligned when removing/installing.

What can go wrong (symptoms + cause)
- Fluid leak under car or wet components: leaking hose, crimp, pump seal, rack seal, or loose fitting.
- Whining or groaning noise: low fluid level, air in system, worn pump, slipping belt, or internal rack cavitation.
- Hard steering (heavy effort): no hydraulic assistance — pump dead, broken belt, blocked hose, or internal leak in rack (pressure not reaching piston).
- Wandering/uneven steering/pull: misaligned rack, unequal assist, stuck return path, or worn tie rods/ball joints.
- Foamy fluid or bubbles: air ingress from cracked hose, loose fittings, or reservoir cap.
- Excessive play in steering wheel: worn tie rods, worn rack internal gear, or loose steering shaft coupler.

Tools and supplies (basics)
- Jack, jack stands, wheel chocks
- Metric socket set, ratchet, extensions
- Torque wrench (use factory specs)
- Flare‑nut wrench (for hose fittings)
- Screwdrivers, pliers
- Tie‑rod separator or pickle‑fork (for outer tie rod removal)
- Pulley puller/installer (some pump pulleys must be transferred)
- Drain pan, fluid funnel, rags, solvent for cleanup
- Replacement parts: pump (or rebuild kit), high‑pressure hose(s), return hose clamps, rack (or rebuild kit), inner/outer tie rods, boots, new crush washers/O‑rings, power steering fluid (Toyota PS fluid or DEXRON ATF per spec)
- Optional: power steering pressure gauge (for diagnosis)

Basic diagnosis steps (quick)
1. Check fluid level and color. Low = likely leak. Dark/burnt or metal bits = pump or internal wear.
2. Inspect for visible leaks at pump, hoses, fittings, boots, rack seams.
3. With engine off, turn wheel lock‑to‑lock to feel resistance and listen for noise. With engine idling, a healthy system is quiet and easy to turn. Whine at idle that changes with RPM indicates pump; whine under load (turning) could be pump or low fluid.
4. If leak source is known, replace that component. If uncertain, pressure test with gauge or progressively replace suspect hoses/pump and check again.

Common beginner repairs — procedures

A. Replacing a high‑pressure hose (most common, relatively simple)
- Purpose: hose cracks/ruptures or fittings leak.
Steps:
1. Raise front, support on stands, remove wheel for easier access.
2. Place drain pan under hose/fittings. Clean area.
3. Loosen hose fittings with flare‑nut wrench; then remove clamps for return hose. Cap fittings to avoid contamination.
4. Remove hose and compare to new hose; replace crush washers or O‑rings on fittings.
5. Install new hose, tighten fittings snug with appropriate flare‑nut wrench (don’t overtighten — use factory torque).
6. Refill reservoir to cold level. Bleed system (see bleeding procedure below).
7. Check for leaks and re‑check level after a few cycles.

Notes: Always replace high‑pressure hose if cracked or soft. Use new crush washers to avoid leaks.

B. Replacing the power steering pump
- Purpose: whining, internal failure, visible leak from pump shaft or housing.
Steps:
1. Disconnect battery negative (optional but good practice).
2. Loosen belt tensioner and remove drive belt (or remove belt from pump pulley). Keep belt routing picture.
3. Drain reservoir into pan by removing return hose or using syringe. Cap hoses.
4. Remove pump mounting bolts and electrical connectors (if any). If you’re swapping pump pulley, use a pulley puller to remove pulley from old pump and install on new pump (many replacement pumps are sold without pulley). Fit pulleys per included instructions.
5. Transfer hoses to new pump; replace any O‑rings/crush washers. Tighten fittings.
6. Bolt pump into place and reinstall belt at the correct tension (check belt tensioner procedure).
7. Refill reservoir and bleed system. Check for leaks, noise.

Notes: If pump failure was due to contamination, consider flushing rack or replacing hoses to avoid damaging new pump.

C. Replacing rack‑and‑pinion (the big job)
- Purpose: leaking rack seals, internal failure causing loss of assist or excessive play.
General prep: Have the new rack or rebuilt rack, new inner tie rods and boots if needed, and the factory service manual. This job affects steering geometry; you must get a wheel alignment after completion.

Steps:
1. Turn steering wheel to center and lock wheel position (mark wheel position relative to column with tape or scribe). Count the number of turns lock‑to‑lock if needed for re‑centering. Mark the intermediate shaft and rack splines so you can reinstall in same orientation.
2. Chock rear wheels, jack front, support on stands, remove front wheels.
3. Drain fluid into pan by loosening return hose at reservoir or removing lower hose. Clean spilled fluid (it damages paint).
4. Disconnect outer tie‑rod ends from steering knuckles (remove cotter pin and castle nut, then use tie‑rod separator). Leave the outer tie rods attached to knuckle until removed so alignment won’t change unexpectedly — note position or measure if reusing. When removing, count turns to keep same effective length (or better: replace tie rods or plan alignment).
5. Remove any lines or brackets attached to rack. Cap lines to keep contamination out.
6. Unbolt the steering shaft pinch bolt at the rack connection; disconnect the intermediate shaft from the rack. Keep marks aligned.
7. Unbolt the rack mounting bolts that secure it to the body/subframe. Support rack and remove it from vehicle. Note any brackets that must be removed.
8. Transfer any brackets or mounts to new rack if needed. Install new rack into vehicle, aligning marks on shaft and rack. Bolt it in place — snug first, torque to factory specs.
9. Reconnect intermediate shaft and tighten pinch bolts to spec. Reconnect hoses (use new crush washers), clamps, and brackets.
10. Reinstall tie rods to the same thread depth or length as removed (count turns or measure). Tighten tie rod ends to spec and install cotter pins.
11. Refill reservoir and bleed system. Start engine and check for leaks and for proper steering operation.
12. Lower vehicle, torque wheels, and take car for a professional wheel alignment immediately. Steering geometry will be off until aligned.

D. Replacing inner tie rod or boot (less invasive than full rack replacement)
- Remove wheel, loosen outer tie rod or remove its nut and separate from knuckle. Unscrew outer tie rod from inner to free inner rod. Remove clamp on boot and slide boot off to access inner tie rod. Use inner tie‑rod tool to unscrew inner tie rod from rack. Install new inner tie rod/boot and reassemble. Count turns/measure to approximate alignment but still get an alignment afterwards.

Bleeding the system (to remove air)
- After any open hose or pump/rack swap you must bleed air:
1. Fill reservoir to the proper cold level.
2. With engine OFF, turn steering wheel slowly from lock to lock 8–12 times. This helps move air toward the reservoir. Check fluid level often and top up.
3. Start engine and let idle. Turn wheel slowly from lock to lock several times. Watch fluid for bubbles/foam and top up. Repeat until bubbles stop and fluid level is stable.
4. Some people raise the front wheels and have an assistant turn the wheel while you watch fluid; this is faster. Never allow pump to run dry while bleeding.
5. Road test slowly and recheck for leaks and fluid level after a short drive.

Troubleshooting tips
- Persistent whining after bleeding: check level again, tighten belt, inspect hoses for collapse, or faulty pump.
- Steering still heavy: check belt, confirm rack received pressure (pressure gauge if available).
- Leaks persist: inspect for hairline cracks and fittings; replace clamps and crush washers as needed.
- Excessive play after rack replacement: likely incorrect reinstallation or worn tie rods; get alignment and check inner/outer rod tightness.

Maintenance tips to avoid future problems
- Check and top fluid periodically; don’t let the reservoir run low.
- Replace hoses every 8–12 years or if you see cracking or swelling.
- Keep boots intact to prevent dirt from cutting rack seals.
- If a major internal failure occurs, replace both rack and pump if contamination was present.

Final notes
- Some tasks (especially rack removal/installation and pulley transfer) require special tools and care. If you are unsure, take photos and mark parts before removal so reassembly is identical.
- Always follow the Toyota factory service manual for your exact model year for torque specs, hose routing, and fluid specification.
- After any steering component replacement, get a professional wheel alignment.

That’s the complete practical overview and step‑by‑step for typical power steering repairs on a Toyota 5S‑FE. Follow safety practices, do the bleeding thoroughly, replace seals/crush washers whenever you open a high‑pressure fitting, and get an alignment after any rack or tie‑rod work.
